Basic parameters
Model name
Chuanqi E8 PHEV 2024 150km max
FAW Audi
GAC Trumpchi
Compact SUV
Medium MPV
Gasoline
plug-in hybrid
National VI
Time to market
Maximum power (kW)
2024.09
WLTC pure electric cruising range (km)
116
CLTC pure electric cruising range (km)
150
Fast charging time (hours)
0.5
Slow charging time (hours)
3.5
Fast charging percentage
-
Maximum power(kW)
-
Maximum torque (N┬╖m)
-
Engine
2.0L 140hp L4
Motor(Ps)
182
gearbox
2nd gear DHT
Length*width*height (mm)
4920*1900*1760
body structure
5-door, 7-seater MPV
Maximum speed (km/h)
170
Official 0-100km/h acceleration (s)
8.8
WLTC comprehensive fuel consumption (L/100km)
1.13
Electric energy equivalent fuel consumption (L/100km)
2.13
Vehicle warranty
Three years or 100,000 kilometers
First owner warranty policy
-
Body
length (mm)
4920
width (mm)
1900
height (mm)
1760
wheelbase (mm)
2930
front wheelbase (mm)
1618
rear wheelbase (mm)
1640
approach angle (┬░)
13
departure angle (┬░)
17
body structure
MPV
door opening method
Swing door sliding door
number of doors (units)
5
Number of seats (seats)
7
Fuel tank volume (L)
50
Trunk volume (L)
345-1917
Curb weight (kg)
2175
Maximum full load mass (kg)
2700
Engine
Engine model
4B20L1
Displacement (mL)
1999
Displacement(L)
2.0
Intake form
naturally aspirated
Engine layout
horizontal
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Valve train
DOHC
Maximum horsepower (Ps)
140
Maximum power(kW)
103
Maximum power speed (rpm)
6000
Maximum torque (N┬╖m)
180
Maximum torque speed (rpm)
4500
Maximum net power (kW)
103
fuel form
plug-in hybrid
fuel grade
No. 92
Fuel supply method
direct injection
Cylinder head material
Aluminum alloy
Cylinder material
Aluminum alloy
National VI
Time to market
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
134
Total motor power (Ps)
-
Total torque of motor (N┬╖m)
300
Maximum power of front electric motor (kW)
134
Maximum torque of front electric motor (N┬╖m)
300
Number of drive motors
single motor
Motor layout
prefix
Battery type
Ternary lithium battery
Battery brand
Jiangsu Zhengli
Battery cooling method
liquid cooling
WLTC pure electric cruising range (km)
116
CLTC pure electric cruising range (km)
150
Battery energy (kWh)
25.57
Electricity consumption per 100 kilometers (kWh/100km)
18.8
Battery pack warranty
-
Fast charging function
support
Fast charging time (hours)
0.5
Slow charging time (hours)
3.5
Fast charging capacity (%)
-
gearbox
Number of gears
2
Gearbox type
Dedicated Hybrid Transmission (DHT)
abbreviation
2nd gear DHT
chassis steering
Drive mode
Front wheel drive
four-wheel drive
-
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
torsion beam non-independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
ventilated disc
Parking brake type
Electronic parking
Front tire specifications
225/50 R18
Rear tire specifications
225/50 R18
Spare tire specifications
Tire repair tools
