Basic parameters
Model name
帕萨特插电混动 2025款 430PHEV 混动商务版
Manufacturer's guide price (yuan)
21.715万
FAW Audi
SAIC Volkswagen
Compact SUV
mid-size car
Gasoline
plug-in hybrid
National VI
Time to market
Maximum power (kW)
2024.09
NEDC pure electric cruising range (km)
63
WLTC pure electric cruising range (km)
52
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging percentage
-
Maximum power(kW)
155
Maximum torque (N·m)
400
engine
1.4T150 horsepowerL4
Motor(Ps)
116
gearbox
6-speed wet dual clutch
Length*width*height (mm)
4948*1836*1469
body structure
4-door, 5-seat sedan
Maximum speed (km/h)
200
Official 0-100km/h acceleration (s)
7.7
NEDC comprehensive fuel consumption (L/100km)
1.4
WLTC comprehensive fuel consumption (L/100km)
2.23
最低荷电状态油耗(L/100km)
5.5
Electric energy equivalent fuel consumption (L/100km)
2.06
Vehicle warranty
To be investigated
First owner warranty policy
-
Body
length (mm)
4948
width (mm)
1836
height (mm)
1469
wheelbase (mm)
2871
front wheelbase (mm)
1584
rear wheelbase (mm)
1570
approach angle (°)
14
departure angle (°)
14
body structure
sedan
door opening method
swing door
number of doors (units)
4
Number of seats (seats)
5
Fuel tank volume (L)
50
Trunk volume (L)
400
Curb weight (kg)
1750
Maximum full load mass (kg)
2210
engine
Engine model
EA211-DXJ
Displacement (mL)
1395
Displacement(L)
1.4
Intake form
turbocharging
Engine layout
horizontal
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Valve train
DOHC
Maximum horsepower (Ps)
150
Maximum power(kW)
110
Maximum power speed (rpm)
6000
Maximum torque (N·m)
250
Maximum torque speed (rpm)
1750-2000
Maximum net power (kW)
110
fuel form
plug-in hybrid
fuel grade
No. 95
Fuel supply method
direct injection
Cylinder head material
Aluminum alloy
Cylinder material
Aluminum alloy
National VI
Time to market
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
85
Total motor power (Ps)
-
Total torque of motor (N·m)
330
Maximum power of front electric motor (kW)
85
Maximum torque of front electric motor (N·m)
330
System comprehensive power (kW)
155
System comprehensive torque (N·m)
400
Number of drive motors
single motor
Motor layout
prefix
Battery type
Ternary lithium battery
Battery brand
SAIC Volkswagen
Battery cooling method
liquid cooling
NEDC pure electric cruising range (km)
63
WLTC pure electric cruising range (km)
52
Battery energy (kWh)
13
Electricity consumption per 100 kilometers (kWh/100km)
18.2
Battery pack warranty
Eight years or 120,000 kilometers
Fast charging function
-
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging capacity (%)
-
gearbox
Number of gears
6
Gearbox type
Wet dual-clutch transmission (DCT)
abbreviation
6-speed wet dual clutch
chassis steering
Drive mode
Front wheel drive
four-wheel drive
-
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
disc type
Parking brake type
Electronic parking
Front tire specifications
215/60 R16
Rear tire specifications
215/60 R16
Spare tire specifications
Tire repair tools
